Hyundai Santa Fe Plug-in Hybrid (PHEV) Repair Manual – PDF & USB

The Hyundai Santa Fe Plug-in Hybrid (PHEV) blends efficiency, electric range, and advanced technology. Whether you’re maintaining the 1.6L turbocharged hybrid engine, servicing the 13.8 kWh high-voltage battery, or troubleshooting the charging system, our repair manuals provide OEM-grade procedures for accurate diagnosis and repair. Available as a PDF download or USB format, these manuals are essential for any technician or serious DIY owner.

🔧 Comprehensive Hybrid & Plug-in Powertrain Service

• 1.6L T-GDI engine and electric motor integration

• High-voltage lithium-ion battery maintenance and diagnostics

• Power Control Unit (PCU), inverter, and charging system repair

• Regenerative braking and hybrid transaxle service procedures

⚡ EV Charging System & Battery Management

• AC Level 1 & Level 2 charging troubleshooting

• Battery Management System (BMS) and thermal control

• Safety procedures for high-voltage service and isolation fault repair

📡 SmartSense ADAS & Sensor Calibration

• Forward Collision Avoidance, Lane Keep Assist, Blind Spot Detection

• Camera and radar sensor calibration for Smart Cruise Control and Parking Assist

• Troubleshooting for ADAS faults and ECU communication issues

📘 Wiring Diagrams & Electrical Systems

• Hybrid and PHEV-specific wiring schematics

• CAN bus diagnostics, ECU pinouts, and control module testing

• Step-by-step troubleshooting for relays, fuses, and grounding issues

🧰 Routine Maintenance & Scheduled Service

• Hybrid-specific fluid checks, filters, brakes, and cooling system

• Plug-in hybrid service intervals and torque specifications

• Pre-trip inspections and system status resets

✅ Why Choose This Santa Fe PHEV Workshop Manual?

• Covers 2021–present Santa Fe Plug-in Hybrid models

• Follows OEM repair procedures for accuracy and safety

• Includes wiring diagrams, battery service, and charging system diagnostics

• Instant access via PDF download or shipped USB drive

• Ideal for professional repair shops and advanced DIYers

🛒 Order Your Hyundai Santa Fe PHEV Repair Manual Today

Maintain your Santa Fe Plug-in Hybrid with confidence. Whether servicing the hybrid drive, charging system, or ADAS features, this manual provides expert-level support for every system.
